[VIP The 1 year ] Index:2
Wheel Size (Inch) 20-28
Size: A/B/C 75.7/34.5/251.5
Size: D/E/F 236.5/M12x1.25-6g/5.4
Size: G/H 15.2/40.9
WL/WR 62.1/72.9
O.L.D 135mm
Parameter
Construction Gear Drive
Rated Voltage (DC) 36V/48V
Rated Power (W) 250~750
Max Torque (Nm) 44~65
Max Efficiency（%） ≥80%
Weight(kg) 5.0/5.5
Color Black
Noise Grade (dB) <55
OperationTemperature (°C) -20~55
Mounting Parameters
Brake Type Disc Brake
Cable Routing hrough Shaft, Left
Cable Length (mm) 250
Connector 3+6Pin Male Connector
Spoke Spectification 36H*13G
Free Wheel Screw-on 10S
Certifications CE/RoHS
Tests Waterproof: IPX5
Salt Spray Test Standard(h): 96h
Speed Sensor NO
Reduction Ratio NO
Magnet Poles 48
Usage eMTB
