KPV-20M(R2) Automatic Polarity & Short Circuit Test Machine For Motorcycle Battery
SEQUENCE OF OPERATION:
After the elements groups are put into the container, the battery is delivered to this tester by conveyor. When the battery enters into the testing area, it's automatically located and stopped in the place. The probe goes down to touch intercells of battery for testing; when testing time is up, the probe is raised automatically. If cell of elements group was found wrong, the machine will be alarm, then the battery be will pass to the end of machine and be rejected automatically. User may connect the extra conveyor for returning the reject battery to change the wrong cell. Upon completion of both testing, the battery is pass to the output conveyor for next process.
FEATURE:
* It is suitable to test all types of motorcycle battery.
* It is easy to change the test probe (mold) of this machine.
* It is equipped with the system of auto-stop of no feeding and auto-start of re-feeding
* Plate group is required with 5mv available.
