Through Authenticate
Feature
1. Plunger, Air Chamber with SUS#304 which corruption resisted.
2. Graphite Iron made Pump that heavy duty and durable.
3. Ceramic of by pass Valve, that durable.
4. Triple Plungers that make pressure steady.
5. Driving lightly, Power can be used Electric Motor or Engine.
6. Good application for Inset pest control for Garden, Agriculture industry, Pipe testing , high pressure washing, ect.
Specification
|
Model |
LS-22 |
LS-30 |
|
LxWxH |
350x280x335mm |
410x305x380mm |
|
Dry Weight |
10kgs |
12kgs |
|
Plunger Dia. |
22mm |
30mm |
|
Suction Capacity |
9.5~19L/min |
17~34L/min |
|
R.P.M |
500~1000rpm |
500~1000rpm |
|
Plunger NO. |
3 |
3 |
|
Working pressure Max. |
35kgf/cm2 |
35kgf/cm2 |
|
Working pressure |
15~45kgf/cm2 |
15~45kgf/cm2 |
|
Power Required Hp |
1~2HP |
1.5~3HP |
|
Engine PS |
3.5PS |
5.5PS |
|
Ceramic Plunger |
Stainless Steel |
Stainless Steel |
