Principle
|
||||||
|---|---|---|---|---|---|---|
|
Photometric System :
|
LEDs 340nm~940nm wavelength
|
|||||
|
Samples & Reagent
|
||||||
|
Sample :
|
Whole Blood, Plasma, Serum , 200μL
|
|||||
|
Reagent Disc :
|
One-Time-Use, self-contained reagent in dry form.
Wet chemistry reaction. Up to 15 assays in a test , with build in QC and calibration. |
|||||
|
System Design
|
||||||
|
User Interface :
|
Touch screen 5 inch Color LCD
|
|||||
|
Internal Memory :
|
Store up to 50,000 analysis results
|
|||||
|
Printer :
|
Build in Thermal printer , External USB Printer
|
|||||
|
Rear Panel Sockets :
|
USB type A (Host) ; RS232 serial port ; RJ45 (LAN ready)
|
|||||
|
Working Condition
|
||||||
|
Analyzing Time :
|
Less than 15min
|
|||||
|
Operating Condition :
|
10~32℃ Temperature , 5%~95% Humidity
|
|||||
|
Power Supply :
|
Specified AC adaptor, 100~240V, 50/60Hz, Rating 1.4A
|
|||||
|
Dimension & Weight :
|
300mm(H)x223mm(W)x285mm(D) ; 5.5Kg
|
|||||
| Total Available Parameters : (# calculated, * Developing) | ||||
| ALB | ALP | ALT | AMY | AST |
| BUN | CREA | CPK | DBIL | GGT |
| GLU | HDL | LDH | LIPA | TBA |
| TBIL | TC | TG | TP | UA |
| Ca | CI | K | Na | PHOS |
| ALB/GLOB# | eGFR# | GLOB# | IBIL# | LDL# |
| VLDL# | NH3* | CRP* | Mg* | |
