RS232, TCP/IP, USB, embedded alarm clock, 3,000 Fingerprint templates
New version of North Korean algorithms with dependability and accuracy, identification speed obviously improved, process 3,000 fingerprints, no matter good or poor, within 0. 7 second.
Built in embedded standalone module (ZKS208), ARM9 core board, 3 inches TFT color LCD
. Build in Alarm clock to give the correct time
. Be equipped with system of calendar which is on an equal footing with PC.
. Sensor with quality image, accepts dry, wet fingers.
. Support 360-degree rotation identification, easy to use.
. Adjust image distortion, assure fingerprint matching consistency.
. Accept ODM or OEM, providing system local voice, menu language, software analysis, casing-making.
. It is a good option for enterprise / factory / office / bank use.
Technical Parameters:
User Capacity: 3000
Transaction Storage: 80,000
Period of data: Keep 3 years when no current
Collection rate: Port rate (9600BPS, 19200BPS, 38400BPS)
Verification mode: 1:1, 1: N
FAR: <0. 0001%
FRR: <0. 01%
Response time: <0. 7 second
Alarm clock: Embedded alarm clock
The capacity of connecting net: 255 units (TCP/IP), 31 units (RS485 mode)
Communication: RS232, TCP/IP
Show: ID number, Time, Name
Working mode: Time & attendance, standalone, can work persistently
Time & Attendance mode: Fingerprint, password,
Save function: Turn off device automatically for saving
Size: 178*55*128mm
Power supply: DC9V, 1A (AC 100V to 240 V, 50 to 60 Hz)
Warranty of period: 24 months
Temperature and humidity: 0 - 45, 20%-80%
Options: Proximity card reader, USB port, backup battery
Application: Factory/office/bank/hotel etc
