SPECIFICATIONS |
JOE302 |
JOE322 |
|
Engine type |
water cooled OHC 4 stroke single cylinder |
water cooled OHC 4 stroke single cylinder |
|
Displacement |
288cc |
312cc |
|
Bore/Storke(mm) |
∮75*65.2 |
∮78*65.2 |
|
Compression Ratio |
10.4 : 1 |
10.4 : 1 |
|
Max power |
15.0kw/7100rpm |
15kw/6700rpm |
|
Max torque |
25nm/5500rpm |
28nm/5700rpm |
|
Top speed |
96 km/hr |
99 km/hr |
|
Ignition |
CDI |
CDI |
|
Starter |
Electric Starter |
Electric Starter |
|
Transmission |
CVT + (Lo-Hi Speed/Neutral/Reverse)/Shaft Drive |
CVT + (Lo-Hi Speed/Neutral/Reverse)/Shaft Drive |
|
Dry Weight |
273 kg |
273 kg |
|
L/W/H |
2152/1100/1126 mm |
2152/1100/1126 mm |
|
Front/Rear Brakes |
Disc/Disc |
Disc/Disc |
|
Front/ Rear tires |
AT25*8-12"/AT25*10-12 or others |
AT25*8-12"/AT25*10-12 or others |
|
Fuel Tank Capacity |
14.1L |
14.1L |
|
Loading |
30 pcs/40' HQ (2200/1195/845mm) |
30 pcs/40' HQ (2200/1195/845mm) |
